제품소개
SMPS
SMPS 해외
SMPS-12V Spec
| Model | In Put | Out Put | efficiency | Size(mm) | Certification | ||
|---|---|---|---|---|---|---|---|
| Voltage | Frequency | Voltage | Current | ||||
| 30W-12V-DYLED | 200~240V | 60Hz | DC 12V | 2.2A | 84% | 165 x 27 x 19.5 | CE / BIS / Saso / UL / KC |
| 60W-12V-DYLED | 200~240V | 4.6A | 93% | 174 x 35 x 18.5 | |||
| 100W-12V-DYLED | 170~240V | 8.3A | 92% | 118 x 54 x 36 | |||
| 150W-12V-DYLED | 170~240V | 12.5A | 92% | 118 x 54 x 36 | |||
| 200W-12V-DYLED | 170~240V | 16.6A | 92% | 151 x 54 x 36 | |||
| 300W-12V-DYLED | 170~240V | 25A | 92% | 199 x 54 x 36 | |||
| 400W-12V-DYLED | 200~240V | 31A | 93% | 216 x 68 x 43 | |||
| 500W-12V-DYLED | 200~240V | 33A | 93% | 216 x 68 x 43 | |||
SMPS-24V Spec
| Model | In Put | Out Put | efficiency | Size(mm) | Certification | ||
|---|---|---|---|---|---|---|---|
| Voltage | Frequency | Voltage | Current | ||||
| 30W-12V-DYLED | 200~240V | 60Hz | DC 24V | 1.1A | 84% | 165 x 27 x 19.5 | CE / BIS / Saso / UL / KC |
| 60W-12V-DYLED | 200~240V | 2.3A | 93% | 174 x 35 x 18.5 | |||
| 100W-12V-DYLED | 170~240V | 4.15A | 92% | 118 x 54 x 36 | |||
| 150W-12V-DYLED | 170~240V | 6.25A | 92% | 118 x 54 x 36 | |||
| 200W-12V-DYLED | 170~240V | 8.3A | 92% | 151 x 54 x 36 | |||
| 300W-12V-DYLED | 170~240V | 12.5A | 92% | 199 x 54 x 36 | |||
| 400W-12V-DYLED | 200~240V | 15.5A | 93% | 216 x 68 x 43 | |||
| 500W-12V-DYLED | 200~240V | 16.5A | 93% | 216 x 68 x 43 | |||
